Hebei Anmei Electrical Equipment Co., Ltd. is one of the most reliable manufacturers and suppliers of epoxy transformer bushings in China, also supports customized service. If you're going to buy high quality epoxy transformer bushings made in China, welcome to get quotation from our factory.
Electric Epoxy Transformer Bushings
Epoxy transformer bushings are critical insulating and conductive components in transformers, playing a vital role in supporting conductors and isolating electrical potentials during medium and low-voltage power transmission and distribution.&. Leveraging years of technical expertise and refined craftsmanship, Hebei Anmei Electrical Equipment Co., Ltd. delivers high-performance, stable epoxy transformer bushings, safeguarding the reliable operation of power systems worldwide.
Looking back at the product history, the iteration of epoxy transformer bushings has always kept pace with technological innovations in the power industry. Early transformer bushings were mostly made of porcelain, which provided basic insulation but suffered from drawbacks such as poor impact resistance, susceptibility to cracking, and high maintenance costs. With the rise and application of epoxy resin materials, epoxy transformer bushings emerged. Thanks to their excellent insulation performance, mechanical strength, and weather resistance, during medium and low-voltage power transmission and distribution. Since its establishment, Hebei Anmei Electric has been deeply engaged in the epoxy bushing field. From the R&D and trial production of the first-generation products to today's full range of products compliant with ANSI/IEEE C57.19.00, GB/T 4109 and other standards, after multiple rounds of technical upgrades and process optimizations, we have not only overcome industry challenges such as bubble control in epoxy casting and interface leakage prevention, but also developed customized products suitable for special environments such as humid, high-altitude and corrosive conditions according to different working conditions, accumulating rich R&D and production experience.
High-quality products are inseparable from strict raw material control. For Hebei Anmei Electric's epoxy transformer bushings, all core raw materials are selected from high-grade industry standards. The main insulating material is imported high-quality epoxy resin, combined with curing agents, accelerators and other additives, forming a stable epoxy system through precise proportioning, ensuring the product has excellent electrical insulation performance, aging resistance and mechanical strength; the conductive part uses high-purity copper conductors with good conductivity and stable current-carrying capacity, which can effectively reduce transmission losses; external auxiliary materials use weather-resistant silicone rubber or special coatings to improve the product's pollution flashover resistance and UV resistance, extending outdoor service life. All raw materials must undergo strict performance testing before entering the factory, eliminating unqualified materials from entering the production process at the source, building the first line of defense for product quality.
Product Specifications
| Parameter | Value |
| Voltage Rating | 1 kV – 35 kV |
| Current Rating | 630 A – 3,150 A |
| Insulation Material | Epoxy resin |
| Conductor Material | Copper | | Creepage Distance | ≥ 250 mm/kV |
| Standards | ANSI/IEEE C57.19.00, GB/T 4109 |
| Application | Medium and low-voltage distribution systems |
In terms of product advantages, Hebei Anmei Electric's epoxy transformer bushings have outstanding highlights. First, they have excellent electrical insulation performance. The high dielectric strength of epoxy resin and uniform electric field distribution design effectively avoid partial discharge problems, ensuring stable operation of equipment under high-voltage conditions; second, they have high mechanical strength. The epoxy resin cast structure has good impact resistance and bending resistance, can withstand external forces during transportation, installation and operation, and is not easy to crack or deform; third, they have strong weather resistance and corrosion resistance. Special formulas and surface treatment processes allow the products to maintain stable performance in complex environments such as humidity, salt spray, and alternating high and low temperatures, reducing maintenance frequency; in addition, the products have precise dimensions and easy installation, and can be customized with different specifications and colors according to customer needs, adapting to various transformer models and meeting application requirements in different scenarios.
Frequently Asked Questions
Q1: What is the voltage range of your epoxy transformer bushings?
A: Our epoxy transformer bushings are typically rated from 1 kV to 35 kV, suitable for medium and low-voltage distribution systems.
Q2: What standards do your epoxy transformer bushings comply with?
A: Our products comply with ANSI/IEEE C57.19.00 and GB/T 4109 standards, and can be customized to meet other international standards.
Q3: What are the main advantages of epoxy transformer bushings compared to porcelain bushings?
A: Epoxy bushings offer better impact resistance, higher mechanical strength, superior weather resistance, and lower maintenance costs compared to traditional porcelain bushings.
Q4: Can you provide customized epoxy transformer bushings?
A: Yes. As a manufacturer in China, Hebei Anmei supports customized specifications, colors, and designs for special environments such as humid, high-altitude, and corrosive conditions.
Q5: How do I maintain epoxy transformer bushings?
A: Regularly check for cracks, chips, and discharge marks; ensure proper sealing; and perform insulation resistance and dielectric loss tests as needed.
In the future, Hebei Anmei Electric will continue to focus on the technical R&D and process upgrading of epoxy transformer bushings, continuously optimize product performance, expand application scenarios, serve global power customers with higher-quality products, and contribute to the safe and efficient operation of power transmission systems.
